Purpose-built to store cable drums and spindles vertically, so reels are easy to access and dispense, without eating up valuable floor space.

Front mounted
Up to 500kg · max 4267mm high
Centre mounted
Up to 1800kg per level · max 7315mm
Basis
Built into selective pallet racking
Get a quote →View specs
Product details

Spin, pull and dispense, off the floor

Cable racking stores drums and spindles on a horizontal axle, so cable pulls off cleanly and reels stay organised and accessible.

It mounts into selective pallet racking, so you can run a dedicated cable bay or integrate it within an existing run. Two mounting styles cover everything from light reels to heavy industrial drums. Built to Australian Standard AS 4084.

Electrical wholesalersCable manufacturersData & commsIndustrial supplySolar & energy
Technical specifications

Two mounting types

The right type depends on the weight of your drums and how high you need to store them.

Lighter loads

Front Mounted

Load capacity
Lighter loads up to 500kg.
Maximum height
4267mm high.
Pull rule
Loads designed to be pulled no more than 1.5m from the front of the rack.
Pull load limit
Load forces must not exceed an 80kg pull load.
How it mounts
A spindle pipe clips onto the post, holding a drum (up to 500kg) for easy access.
Heavy loads

Centre Mounted

Load capacity
Up to 1800kg per level.
Maximum frame height
7315mm high.
Pull rule
Loads designed to be pulled no more than 1.5m from the front of the rack.
How it mounts
Heavy cable drums stored within selective pallet racking, suits 838mm deep racking, max 1800kg per set.
Not sure which you need? It comes down to drum weight and storage height. Tell us your heaviest drum and how high you want to go, and we'll spec front- or centre-mounted accordingly.
Why it works

Built for reels

Vertical Storage

Drums stored on-axis so cable feeds off cleanly, no tangling or kinking.

Saves Floor Space

Goes vertical inside racking, freeing valuable floor area for other stock.

Easy Access

Pull cable directly from the reel without lifting heavy drums off the rack.

Integrates with Racking

Runs as a dedicated bay or built into your existing selective pallet racking.

Heavy-Duty Option

Centre-mounted handles up to 1800kg per level for big industrial drums.

Configurable Heights

Up to 7315mm with centre-mount, use the full height of your building.

Gallery

Recent installations

A selection of racking and storage systems we’ve installed across Sydney and Greater NSW.

Pallet racking warehouse fit-out
High-density pallet racking aisle
Compliant high-bay racking
Pallet racking installation, Sydney
FAQs

Common questions

What's the difference between front and centre mounted?
Front-mounted suits lighter reels, up to 500kg, max 4267mm high, with an 80kg pull-load limit. Centre-mounted is the heavy-duty option, holding up to 1800kg per level and reaching 7315mm high. The choice comes down to drum weight and storage height.
Does it work with my existing racking?
Yes, cable racking is built into selective pallet racking, so it can run as a dedicated cable bay or be integrated within an existing run. Centre-mounted suits 838mm deep racking.
How far can I pull the cable?
Both types are designed for loads to be pulled no more than 1.5m from the front of the rack. On front-mounted, the pull force must not exceed 80kg.
How heavy can the drums be?
Front-mounted spindles hold up to 500kg per drum. Centre-mounted handles up to 1800kg per set, suitable for large industrial cable drums.
